A super tough chassis for super tough trucks - the ultimate bashers choice. Arrma tough PLUS!
This is a new profile, compatible with all versions V1-V5 and EXB parts (Pictures are of the old type - to be updated!)
Built of 3mm ti 6al-4v, it gives you unparalleled strength and durability to weight. Three times stronger than 6061 aluminium and almost twice as strong as 7075.
This chassis is around 20% stiffer than the stock chassis. This?ÿmeans the chassis will still flex to absorb impacts but will still tauten handling and response.
This is a direct replacement. All standard fixings can be re-used.
Additional expensive skid plates or droop screw stops are not required - the titanium is tough and isnƒ??t going to wear down like aluminium. Taking this into account, the Titanium is the strongest, and also most cost effective choice.
At 540g it is lighter than some other aftermarket chassis whilst making no sacrifice of durability.
A really fun thing also happens - the titanium will give a shower of sparks when it catches hard surfaces!?ÿ
Material Properties Comparison?ÿ
Titanium Ti-6Al-4V
Density ?ÿ ?ÿ4.43 g/cc
Tensile strength to yeild 880 Mpa
Modulas of elasticity ?ÿ 113.8 GPa
?ÿ
Aluminium 6061-T6
Density ?ÿ ?ÿ2.7 g/cc
Tensile strength to yeild 276 Mpa
Modulas of elasticity ?ÿ 68.9 GPa
?ÿ
Aluminium 7075-T6
Density ?ÿ ?ÿ2.81 g/cc
Tensile strength to yeild 503 Mpa
Modulas of elasticity ?ÿ 71.7 GPa
Modifying your RC from stock condition can result in unexpected performance and operation of models must take this into account. Always follow the original manufacturers instructions. Do not use your RC in public areas. Do not use your RC where unexpected results could cause injury or damage to property.?ÿWhilst we build our parts to the highest standards we are able, like all rc parts, our parts cannot be guaranteed for performance, strength and durability in every situation or configuration. We always work with our customers to replace components in the unlikely event that they fall short of the high standards we aim for.
